20x19 Water to Air Heat Exchanger~~1" Copper Ports w/ EZ Install Front Flange

<h2><strong>20x19/152,000BTUs/ 180 PSI</strong><span>For use in yourhot air furnace plenum.</span></h2><p style="text-align: left;"><span><b>***Not recommended for air compressors***</b></span></p><p><strong><u>Information about our heat exchangers</u></strong></p><ul><li><strong>This heat exchanger is ideal for a 20"x 20" plenum or larger.</strong></li><li><strong>The outlets come out on the 20" side (shown as the vertical side in the picture above)</strong></li><li><strong>GPM 15.8 </strong></li><li><strong>CFM 1854 </strong></li><li><strong>The fin area is 20"x 19"</strong></li><li><strong>Outside Dimensions 20”(width)x22.5”(Length from Manifold to Base)x3.5”(Thickness) </strong></li><li><strong>There is a 1" frame on the end opposite the outlets that covers the copper elbows. This makes the area inside of your plenum 1" longer.</strong></li><li><strong>All exchangers are 3 1/2" thick.</strong></li><li><strong>Aluminum fins are installed at 12 fines per inch.</strong></li><li><strong>All exchangers are triple pass design.</strong></li><li><strong>Tubing is 1/4" copper.</strong></li><li><strong>All our exchangers include the flat front face mounting for easier installation and increased plenum strength.</strong></li><li><strong>Our exchangers have 1" copper outlets and can be installed with either sweat fittings or push fit type fittings like sharkbite's.</strong></li><li><strong>Exchangers from us come with a lifetime warranty, including shipping. </strong></li><li><strong>Exchangers will work with chilled water also.</strong></li><li><strong>We stock many sizes, always order the largest size that will fit into your plenum.</strong></li></ul><p>Installation brackets for installing water to air heat exchangers inside of furnace plenums. This easy to install kit takes all of the work out of installing a coil. Great for the do it yourselfer or the seasoned installer</p><p>This kit will work with most coils being sold on other sites that are 3.5" wide. Check before you buy, but that will cover over 90% of the ones being sold. Even most that are listed as 4" are actually 3.5". These will work with every heat exchanger being sold elsewhere and our website store.</p><p><strong>We provide a<u>lifetime warranty</u>against manufacturer's defects and corrosion. </strong></p><h3>These heat exchangers are to be hooked up to a boiler or a chilled water source.</h3><p><strong></strong>These heat exchangers are to be hooked up to a boiler or a chilled water source. When hooked up to your boiler or chilled water source, these heat exchangers can also be usedas a stand alone heat source by simply attaching a fan or squirrel cage to one side of the unit.</p><p>They can be installed in either the hot air side or the cold air return of a furnace. Please note that if installed in the cold air return you will need to install a 3 way zone valve in order for the fan to operate properly.</p><p><strong>This heat exchanger is of a new style which does not require bending of your duct work.</strong></p><p><strong>This new styleheat exchangercan beeasilyinstalled by just slipping it into theplenum and<u>attaching with self threading screws</u>. Youwill notneed any special tools to install. This unit is easier to install than others on the market because it<u>attaches from the front instead of the side</u>.</strong></p>

• This heat exchanger is ideal for a 20"x 20" plenum or larger.
• The outlets come out on the 20" side (shown as the vertical side in the picture above)
• GPM 15.8
• CFM 1854
• The fin area is 20"x 19"
• Outside Dimensions 20”(width)x22.5”(Length from Manifold to Base)x3.5”(Thickness)
• There is a 1" frame on the end opposite the outlets that covers the copper elbows. This makes the area inside of your plenum 1" longer.
• All exchangers are 3 1/2" thick.
• Aluminum fins are installed at 12 fines per inch.
• All exchangers are triple pass design.
• Tubing is 1/4" copper.
• All our exchangers include the flat front face mounting for easier installation and increased plenum strength.
• Our exchangers have 1" copper outlets and can be installed with either sweat fittings or push fit type fittings like sharkbite's.
